Sanitization Tunnel

Product Description

Sanitizer Spray Tunnel

The Sanitizer SprayTunnel (SST)  is designed and installed tosanitize the user with mist spray of 1% Sodium Hypochlorite (Chlorine) in atank of 1000 litres 1 ppm.  Thedrinking water is dosed with 2 ppm; hence 1 ppm is in safe limits

The enclosure isdesigned to spray the solution while passing through or stand for requisite time;which is typically 3-5 secs.  The personpassing through is expected to raise the hands and even rotate slowly.  The nozzles are installed on top or sides orboth to ensure comprehensive sanitizing.

The wideapplications include entrances at:

                                                       Picnic Spots

Theconstructional features include:

Enclosure Frame                    Tubular in MS/SS;Fixed/Foldable

Size (Typical)                          5 Wide x 7 high x12-16 long

Covering                                  SS/CRCA-coated/FRP/Flex

Nozzles                                   Multiple misting type

Nozzle Specs                          0.2 to 0.3 mm

Nozzle Pattern                        Top / Sides /Combination

Pumping                                  Typically upto250 LPH

Pumping Pressure                  Upto 6.0 kg/cm2

Voltage                                    220 V AC

Water Storage                         Tank 200 to 1000 litres

The additional/Optionalfeatures can be:

No person Nospray                Sprayonly when person is inside; to economize water usage

Spray TriggerOptions            Photo sensor atentrance

                                                PaddleSensor

                                                LaserSensor

                                                Infrared

                                                PushButton

Lighting                                   Entry / Exit

Doors                                      Single orEntry/Exit

Hand Wash                             Multiple to matchpersons per 5 to 6 secs
