Powder Coating Plant

530000.00 INR/Unit

Get a Price/Quote

Product Details:

Material Mild Steel
Processing Type Automatic
Condition New
Technology Electrostatic Powder Coating
Dimension (L*W*H) 12000 x 2500 x 3000 mm
Power Mode Electric
Voltage 220-380V
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Powder Coating Plant Price And Quantity

Price 530000.00 INR/Unit
Price Range 530000.00 - 2500000.00 INR/Unit
Minimum Order Quantity 1 Unit

Powder Coating Plant Product Specifications

Application Industrial Metal Surface Coating
Material Mild Steel
Processing Type Automatic
WorkingSpeed Up to 3 m/min
Voltage 220-380V
Technology Electrostatic Powder Coating
Dimension (L*W*H) 12000 x 2500 x 3000 mm
Power Consumption 25-45 kW
Condition New
Weight Approx. 2500 kg
Coating Type Powder Coating
Power Mode Electric

Product Description

We are manufacturer of Powder Coating Lines

Denominations:

Basic Hoist assisted pre treatment line

PLC controlled transporter based dunking system

Spray Pre treatment option

Pre Treatment designed are dip type 7-9 tanks with Civil Constructed tanks/MS Tanks

Material handling of Overhead and ground type are provided

Automatic Electrical Panel and Wiring also a USP for SSA Plants

Execute the project on a turnkey basis

Various Denominations of ovens can be offered from Basic budgetary designs to Industrially accepted designs

Direct Gas Type - c/w Imported Burner and Heat Exchanger OR Ribbon Burner

Indirect Type of Heating System - Suitable for 15' to 18' or more lengths of Aluminium Sections

Basic Plants can hadle from One Ton Production to 10/12 tonns or more

Higher Production Plants will be Conveyoried Type

Advanced Hot Air Circulation Oven

The plant features a precisely engineered hot air circulation oven, achieving uniform and consistent curing at a maximum temperature of 250C. This ensures durable, high-quality powder coating finishes, suitable for a wide range of industrial metals. The ovens efficient design results in minimal heat loss and reliable performance across varied operating conditions.

Efficient Pretreatment Systems

Choose from tunnel, spray, or dip pretreatment systems to prepare metal surfaces thoroughly before coating. Each method ensures optimal adhesion and surface cleanliness, essential for achieving long-lasting coating results. Flexible options allow customization according to specific industrial requirements and throughput needs.

Quick Color Change & High Recovery

This plant incorporates a quick change system that reduces color changeover time to just 15 minutes. Coupled with a pulse jet cartridge filter and a sophisticated paint recovery system, it achieves up to 98% material recovery, minimizing waste and lowering operational costs. The low-noise operation enhances workplace comfort.

FAQs of Powder Coating Plant:

Q: How does the quick color change system work in the powder coating plant?

A: The plant utilizes an advanced quick change system, enabling operators to switch powder colors within 15 minutes. The recovery and filter systems efficiently clean and prepare the booth for the next batch, reducing downtime and improving productivity.

Q: What are the available pretreatment options, and how do I select the right one?

A: Pretreatment systems include tunnel, spray, and dip types. Selection depends on the specific metal substrate, desired throughput, and application requirements. Each method provides superior surface cleaning and preparation to ensure optimal coating adhesion.

Q: When and where can this powder coating plant be used?

A: This plant is designed for industrial environments requiring high-quality surface finishes on metal products. It is ideal for manufacturers, exporters, service providers, and suppliers looking for automatic, large-scale, efficient powder coating capabilities in India.

Q: What process does the powder coating plant follow from start to finish?

A: The process commences with surface pretreatment using spray, tunnel, or dip methods, followed by electrostatic powder application in single or multiple booths. The coated items are then cured in the hot air oven, ensuring thorough adhesion. Finally, any excess powder is recovered, optimizing resource utilization.

Q: How does the PLC-based control panel improve plant operation?

A: The automated PLC-based control panel streamlines the entire powder coating process, allowing precise regulation of oven temperature, conveyor speed, and filter system operations. This ensures consistent results, improved efficiency, and reduced need for manual intervention.

Q: What are the key benefits of the high paint recovery system?

A: With up to 98% recovery, this plant greatly reduces powder wastage and operational expenses. The efficient pulse jet cartridge filter system not only improves recovery but also maintains clean air and a safe working environment.
